Product Description

Looking for seriously simple and affordable flash storage?

The HPE MSA 2062 Storage is a flash-enabled system designed for affordable application acceleration for small and remote office deployments. Don’t let the low cost fool you. The HPE MSA 2062 gives you the combination of simplicity, flexibility and advanced features you many not expect in an entry-priced storage array. Starting with 3.84 TB of embedded flash capacity, you can scale the system from there with any combination of solid state disks (SSD), high-performance Enterprise SAS HDDs, or lower-cost Midline SAS HDDs. Capable of delivering in excess of 325,000 IOPS, the HPE MSA 2062 saves you up to 32% with an all-inclusive software suite and 3.84 TB of flash capacity included. It’s seriously simple and affordable flash storage to help you achieve high performance yet meet challenging budgets.


Affordable Application Acceleration
- The HPE MSA 2062 Storage is capable of delivering over 325,000 IOPS for affordable application acceleration for small to medium-sized businesses.
- Save 32% on HPE MSA 2062 with all-inclusive software and 3.84 TB of Solid State Drive (SSD) capacity included.

MSA’s 'set and forget' Data Services does not Require a Dedicated Storage Administrator to Manage
- The HPE MSA 2060 Storage is easy to install, easy to use, easy to maintain, even for an IT generalist. Administrators will find the MSA 2060’s new Storage Management Utility intuitive and easy to navigate.
- MSA’s automated tiering engine dynamically responds to workload changes so you don’t have to, insuring the hottest data will be moved to the fastest media automatically and in real-time.

Leverage Data Protection Features to Keep your Business Running in the Event of a Disaster
- The HPE MSA 2060 Storage delivers virtualized snapshot technology making data protection and instant recovery a snap.
- Remote replication via Fibre Channel (FC) or iSCSI facilitates affordable disaster recovery solution.
- Encrypted SSDs and HDDs with local key management can be deployed to deliver a secure, encrypted hybrid flash array.

Flexible, Modular Architecture that Facilitates Growth into the Future
- The HPE MSA 2060 Storage supports a mixture of 3.5 inch LFF and 2.5 inch SFF expansion enclosures for a maximum of 9 (10 including base system) enclosures.
- Start small and scale as needed with any combination of SSDs, Enterprise SAS or MidLine SAS HDDs.


Total installed storage capacity3.84 TB
Installed storage drive typeSSD
Number of storage drives installed2
Supported storage drive typesHDD & SSD
Number of storage drives supported24
Storage drive capacity1920 GB
Storage drive size2.5"
Storage drives installedYes
Maximum supported storage capacity921 TB
RAID levels0,1,5,6,10
Data transfer rate16 Gbit/s
Ports & interfaces
USB connectivityNo
Host ports8
Technical details
Device classSmall & Medium Business
Chassis typeRack (2U)
Storage mirroringYes
SAN backup supportYes
Data transfer rate16 Gbit/s
Chassis typeRack (2U)
Device classSmall & Medium Business
Maximum number of controllers supported2
Hard drive
RAID levels0,1,5,6,10
Number of power supply units2
AC input voltage100 - 230 V
AC input frequency50/60 Hz
Redundant power supply (RPS) supportYes
System requirements
Other operating systems supportedYes
Server operating systems supportedWindows Server 2016,Windows Server 2019
Linux operating systems supportedYes
Weight & dimensions
Width445 mm
Depth508 mm
Weight5 kg
Height89 mm
Other features
Controller interface typeFC
Storage mirroringYes
SAN backup supportYes


Product code: R0Q80A
£5,619.91 ex. VAT
15 in stock
